Automotive relay 5P 12V 30A 0.5W NO/NC – ZDCA-12ZS

Home / PCB Relays | ZND / Automotive PCB Relays / Automotive relay 5P 12V 30A 0.5W NO/NC – ZDCA-12ZS

COIL DATA

Suppressor: No

Release Voltage: 1,5V DC @ 23°C

Operate Voltage: 6,9V DC @ 23°C

Num. Terminals: 5P

Rated Voltage: 12V DC

Coil Power: 0.55W

Coil Resistance: 262Ω

CONTACTS DATA

Contact Resistance: 100mΩ (1A 6VDC)

Contacts Arrangement: 1Z (CO/SPDT)

Electrical Lifestime: 1x105OPS(10 OPS/min)

Insulation Resistance: 100MΩ 500VDC

Max Continuous Current: 30A

Max Switching Current: 30A

Mechanical Lifetime: 1x107OPS(300 OPS/min)

Release Time: 10ms max

Rated Load: 30A 16VDC

Operate Time: 10ms max

OTHER DATA

Dielectric Strength Between Open Contacts: 500VAC 1min

Dielettric Strenght: 500VAC 1min

Operating Temperature: -40℃ to 105℃

MATERIALS

Terminals: Silver Alloy

ADDITIONAL DATA

Cross Reference: HFKC/012-ZST

Vibration Test (ISO 16750-3): 10HZ to 55HZ 1.5mm Double amplitude

PACKAGING

MOQ: 2000

Anchor | Bracket: NO

WEIGHT

Single Net Weight: ≈4g
