HEAVY DUTY RELAY 12V 2,4W 180A N.O. WHIT PLASTIC BRACKET EXTRA SMALL – R12V180XS.A1

Home / Heavy Duty Relays up to 230A / Heavy Duty Relays / HEAVY DUTY RELAY 12V 2,4W 180A N.O. WHIT PLASTIC BRACKET EXTRA SMALL – R12V180XS.A1

COIL DATA

Coil Power: 2,4W

Coil Resistance: 60Ω

Operating Voltage: 8,5V÷15,6V

Rated Voltage: 12VDC

Operate Voltage: ≤8,5V

Release Voltage: ≥1,2V

CONTACTS DATA

Release Time: <5ms

Rated Current On The Contacts: 180A

Electrical Lifestime: 5x10^4 cycles @ 5” ON / 10”OFF @ 200A

Contacts Arrangement: 1A - 1H (NO/SPST)

Insulation Resistance: 100M Ω @ 500VDC

Max Switching Current: 200A

Mechanical Lifetime: 1x10^6 cycles (Without load)

Operate Time: <10ms

OTHER DATA

Dielettric Strenght: 500VAC/m

Operating Temperature: -40°C÷ 85°C

MATERIALS

Baseplate: PA66 GF30

Fixed Contact: AgSnO2In

Housing: PA66

Screw Terminals: FeZn (size M6)

PACKAGING

Anchor | Bracket: With Plastic Bracket

WEIGHT

Single Net Weight: ~85g
