LED Flasher Unit – 100.102.01.LED

Home / Flashers & Solutions for LED Conversion / Flasher for LED Indicators / LED Flasher Unit – 100.102.01.LED

Without Failure Detection

COIL DATA

Num. Terminals: 2

Operating Voltage: 10 ÷ 15V

Pull - In Voltage: ≤ 10V @ 23°C

Rated Load: Max 30W

Rated Load During Hazard Warning: 30W

Rated Voltage: 12V DC

CONTACTS DATA

Electrical Lifestime: 400h Continuous

Electrical Lifetime in Hazard mode: 36h

PROTECTIONS

Degree Protection: IP 54 DIN40050

OTHER DATA

Connection: Quick Connected Terminals

Flashing Frequency: 85 ±15 CPM

Flashing Frequency during the failure warning: NO

Duty Cycle: 50% (±3)

Operating Temperature: -30°C ÷ 70°C

Diagnostics: Not Present, any failure warning

Storage Temperature: -45°C ÷ 110°C

Test Temperature: + 23°C

MATERIALS

Terminals: Cu Zn

Housing: PA 66 GF30

Baseplate: PA 66 GF30

ADDITIONAL DATA

Homologation Number: 10R-02 7394

Preferential Origin: Made in Italy

In Conformity with: EU Dir. 2002/95/EC RoHS

Company IMDS: 75948

Terminals Assignment: ISO 8092

Terminals Assignment/Terminal Number Assignmet: ISO 7588-1

Salt Spray Test (ISO 16750-3): 96h @ 5% NaCl

PACKAGING

Packing Options: 1pcs/30pcs/300pcs

Anchor | Bracket: Included

WEIGHT

Single Net Weight: 28g
